MAD Wood Shafts

The team in the R&D lab at Graphite Design Japan went all out when designing the Graphite Design MAD wood shafts.  A challenge was issued to them to design a shaft that would alleviate the ill-fated golf ball flight issues that results in a lack of Maximum Accuracy and Distance.  Accepting the challenge, they went to work in an effort to develop a cure.

The Graphite Design MAD shaft is their response.  Available in two strengths, the Graphite Design MAD  Standard strength wood shafts are available in a 55g R and S Flex, 65g R and S Flex and a 70g S Flex and is designed for the intermediate to advanced players.

The Graphite Design MAD PRO strength wood shafts are available in 65g S, X and TX Flex and 75g X and TX Flex and are designed for the advanced to professional players with higher swing speeds.

Make an appointment with your local professional golf club fitter and request that he write you a prescription for a new Graphite Design MAD shaft to cure your ball flight issues that may be holding you back from achieving Maximum Accuracy and Distance.

MSI_side_image

Features & Technology:

  • TORAYCA ® T1100G carbon-fiber pre-preg with NANOALLOY ® technology for increased stability in the mid to tip region and unsurpassed feel.
  • Premium, ultra-thin, aerospace quality carbon fiber materials.
  • Graphite Design proprietary Material Stiffness Integration (MSI) design philosophy and technology.

Bend Profile:

SHAFT BUTT Section MID Section TIP Section
MAD MEDIUM+ FIRM+ MEDIUM+
MAD PRO FIRM STIFF FIRM

Performance:

MAD

  • Designed to promote Mid to Mid/High launch angles with Low/Mid to Mid ball spin rates.
  • TORAYCA ® T1100G carbon-fiber pre-preg with NANOALLOY ® technology for increased stability in the mid to tip region and unsurpassed feel.
  • Ultra-premium, high modulus, aerospace quality carbon fiber materials.
  • Graphite Design proprietary Material Stiffness Integration (MSI) design philosophy and technology.
  • MSRP $175

MAD PRO

  • Designed to promote Mid launch angles with Low ball spin rates.
  • TORAYCA ® T1100G carbon-fiber pre-preg with NANOALLOY ® technology for increased stability in the mid to tip region and unsurpassed feel.
  • Ultra-premium, high modulus, aerospace quality carbon fiber materials.
  • Graphite Design proprietary Material Stiffness Integration (MSI) design philosophy and technology.
  • MSRP $275

Fitting:

Shaft Flex Fitting recommendations are based on the player’s Driver Swing Speed
71-85 MPH 86-95 MPH 96-105 MPH 106-109 MPH 110+ MPH
A Flex
(Lite/Senior)
R Flex
(Regular)
S Flex
(Stiff)
X Flex
(X-Stiff)
TX Flex
(Tour X-Stiff)

Tip Trimming for Std Bore:

Driver 3 Wood 5 Wood 9 Wood
0″ 0.5″ 1.0″ 1.0″
  • Pro’s Choice encourages consulting a PGA Professional or qualified club builder to help you determine the correct shaft and length for your swing profile and to meet your goals.
  • Always leave a minimum of 0.5″ of the parallel tip section of the shaft above the hosel to maintain shaft durability and prevent shaft failure/breakage.  For example, if the head has a hosel bore depth of 1.5″ and the shaft has a parallel tip length of 3.0″, the tip trim length should not exceed 1.0″.
  • Improper installation may affect the intended performance of the shaft. Warranty is for material and workmanship of our products. Improper installation voids warranty of product.

Specifications:

Shaft Type Part Number Flex Length Wt. Tip OD Tip Para. Butt OD Torque Kick pt Launch Spin
MAD 65 PRO Stiff Flex MAD6T-S Stiff 46″ 67g .335″ 3.0″ .615″ 3.8 MID MID LOW
MAD 65 PRO X-Stiff Flex MAD6T-X X-Stiff 46″ 68g .335″ 3.0″ .616″ 3.8 MID MID LOW
MAD 65 PRO TX Flex MAD6T-TX Tour X-Stiff 46″ 69g .335″ 3.0″ .618″ 3.8 MID/HIGH LOW/MID LOW
MAD 75 PRO X-Stiff Flex MAD7T-X X-Stiff 46″ 77g .335″ 3.0″ .620″ 3.2 MID MID LOW
MAD 75 PRO TX Flex MAD7T-TX Tour X-Stiff 46″ 77g .335″ 3.0″ .620″ 3.2 MID/HIGH LOW/MID LOW
MAD 55 Regular Flex MAD5C-R Regular 46″ 60g .335″ 3.0″ .612″ 4.7 LOW/MID MID/HIGH MID
MAD 55 Stiff Flex MAD5C-S Stiff 46″ 61g .335″ 3.0″ .613″ 4.6 LOW/MID MID/HIGH MID
MAD 65 Regular Flex MAD6C-R Regular 46″ 66g .335″ 3.0″ .612″ 4.4 LOW/MID MID/HIGH LOW/MID
MAD 65 Stiff Flex MAD6C-S Stiff 46″ 68g .335″ 3.0″ .614″ 4.4 MID MID LOW/MID
MAD 75 Stiff Flex MAD7C-S Stiff 46″ 75g .335″ 3.0″ .616″ 3.8 MID MID LOW/MID
